| 标称截面(mm2) | 根数/线径(mm) | 绝缘厚度(mm) | 平均外径(mm) | 20˚C时导体直流电阻（Ω/km） | 包装长度(m) |
| 0.014 | 7/0.05 | 0.15 | 0.45 | 1343 | 500 |
| 0.035 | 7/0.08 | 0.15 | 0.60 | 525 | 500 |
| 0.05 | 7/0.10 | 0.15 | 0.60 | 330 | 500 |
| 0.08 | 7/0.12 | 0.20 | 0.78 | 227 | 500 |
| 0.12 | 7/0.15 | 0.20 | 0.85 | 150 | 500 |
| 0.20 | 7/0.20 | 0.25 | 1.10 | 83.5 | 200 |
| 0.35 | 19/0.16 | 0.25 | 1.30 | 49.5 | 200 |
| 0.50 | 19/0.18 | 0.25 | 1.40 | 36.0 | 200 |
| 0.75 | 19/0.23 | 0.25 | 1.70 | 22.7 | 200 |
| 1.0 | 19/0.26 | 0.25 | 1.80 | 19.0 | 200 |
| 1.20 | 19/0.28 | 0.30 | 2.0 | 15.3 | 200 |
| 1.50 | 19/0.32 | 0.30 | 2.20 | 11.7 | 200 |
| 2.0 | 19/0.37 | 0.30 | 2.45 | 9.45 | 100 |
| 2.5 | 19/0.41 | 0.40 | 2.95 | 6.86 | 100 |
| 4.0 | 37/0.37 | 0.40 | 3.40 | 4.51 | 100 |
| 6.0 | 37/0.45 | 0.50 | 4.20 | 3.05 | 100 |
| 8.0 | 133/0.28 | 0.50 | 5.20 | 2.16 | 100 |
| 10 | 133/0.32 | 0.50 | 5.80 | 1.68 | 100 |
| 16 | 133/0.39 | 0.60 | 7.00 | 1.13 | 100 |
| 20 | 133/0.45 | 0.60 | 8.0 | 0.886 | 100 |
| 25 | 196/0.40 | 0.6 | 8.8 | 0.734 | 100 |
| 35 | 494/0.30 | 0.7 | 10.4 | 0.511 | 100 |
| 50 | 551/0.40 | 0.8 | 12.2 | 0.358 | 100 |
| 70 | 551/0.40 | 1.0 | 14.6 | 0.270 | 100 |
| 95 | 760/0.40 | 1.2 | 17.2 | 0.210 | 100 |
| 0.03 | 1/0.20 | 0.15 | 0.50 | 560 | 500 |
| 0.05 | 1/0.26 | 0.17 | 0.60 | 386.9 | 500 |
| 0.07 | 1/0.30 | 0.20 | 0.70 | 245 | 500 |
| 0.12 | 1/0.40 | 0.20 | 0.80 | 146.9 | 500 |
| 0.2 | 1/0.50 | 0.25 | 1.0 | 94 | 500 |
| 0.3 | 1/0.60 | 0.30 | 1.20 | 65.3 | 500 |
| 0.5 | 1/0.80 | 0.3 | 1.40 | 36.7 | 500 |
| 0.75 | 1/0.97 | 0.26 | 1.50 | 24.7 | 500 |
| 1.13 | 1/1.20 | 0.30 | 1.80 | 16.5 | 500 |
| 注：根据供需双方协议，可以生产其他规格产品 | |||||
